LPM-102 Lipid Profile Panel Blood Test For TC / HDL / TG / LDL Analysis

ivd-medical-equipment
  • ivd-medical-equipment
  • ivd-machine
  • ivd-analyzer
  • in-vitro-device-regulation

Product Details:

Place of Origin: China

Brand Name: Lysun

Certification: CE/ISO9001/RoHS

Model Number: LPM-102

Payment & Shipping Terms

Payment Terms: D/A, L/C, D/P, T/T, Western Union, MoneyGram


Introducing the LPM-102 Lipid Test from Lysun - a revolutionary device that combines convenience and accuracy for lipid testing at home.

With the LPM-102, you can easily test your Total Cholesterol (TC), High Density Lipoprotein Cholesterol (HDL), and Triglycerides (TG) all in one device in just 120 seconds. This makes it a quick and convenient option for individuals who want to monitor their lipid levels without having to go to a medical facility.


Features of Lysun LPM-102 Lipid Profile Panel Blood Test For TC / HDL / TG / LDL Analysis

  • One of the standout features of the LPM-102 is its micro specimen capability, requiring only 35 ul of whole blood (capillary and venous), plasma, or serum for testing. This means that you can perform lipid tests from the comfort of your home without the need for expensive lab tests.


  • The LPM-102 is also portable, making it easy to use wherever you go. Its built-in lithium battery can endure up to 300 cycles of charging, and the device can hold up to 500 records in its memory. After displaying the results, the LPM-102 automatically shuts off after 5 minutes.


  • The intelligent design of the LPM-102 allows for easy printing of results through its linkable printer feature. This makes it simple for individuals to keep track of their lipid levels and monitor their progress over time.


  • The LPM-102 uses reflectance photometry for its analysis methodology and provides a measurement range of TC: 2.59-12.93 mmol/L (100-500 mg/dL, 1mmol/L=38.66mg/dL), HDL: 0.39-2.59 mmol/L (15-100 mg/dL, 1mmol/L=38.66mg/dL), and TG: 0.51-7.34 mmol/L (45-650 mg/dL, 1mmol/L=38.66mg/dL). It measures in both mmol/L and mg/dL units for ease of use.


  • The LPM-102 is reliable and built to last, with a shelf life of 4 years and a warranty period of 2 years. The meter and test strip storage conditions are 0-55℃ and 2~30℃ respectively, with a maximum operating altitude of 2000m above sea level.


  • Overall, the LPM-102 Lipid Test from Lysun offers a cost-effective and convenient solution for individuals looking to monitor their lipid levels. With its portable and intelligent design, you can easily test and keep track of your lipid levels at home.


Specification of Lysun LPM-102 Lipid Profile Panel Blood Test For TC / HDL / TG / LDL Analysis

Specimen:
Whole Blood (capillary And Venous), Plasma And Serum
Power Source:
3X AAA Battery
Units Of Measurement:
Mmol/L, Mg/dL
Memory:
500 Records
Meter Size:
135*66*19mm (LWH)
Weight:
90g
Meter Storage Conditions:
0-55℃; ≤90%RH
System Operating Conditions:
10-35C; 0-90% RH; Height < Seal-level 2000m
Test Strip Storage Conditions:
2~30℃; ≤90% RH
Warranty Period:
2 Years


MethodologyReflectance Photometer
Measurement Range:

TC: 2.59-12.93 mmol/L (100-500 mg/dL, 1mmol/L=38.66mg/dL)

HDL: 0.39-2.59 mmol/L (15-100 mg/dL, 1mmol/L=38.66mg/dL)

TG: 0.51-7.34 mmol/L (45-650 mg/dL, 1mmol/L=38.66mg/dL)

SpecimenWhole blood (capillary and venous), plasma and serum
Power Source3X AAA battery
Battery EnduranceAfter cycle charge 300 times, electric quantity reduce 30%
Units of Measurementmmol/L, mg/dL
Memory500 records
Automatic Shut Off5 minutes after displaying results
Meter Size135*66*19mm (LWH)
Weight90g
Meter Storage Conditions0-55℃; ≤90%RH
System Operating Conditions10-35C; 0-90% RH; height < seal-level 2000m
Test strip Storage Conditions2~30℃; ≤90% RH
Warranty Period2 years
Meter Shelf Life4 years
